25hp Mini Skid Steer Loader DH525L

Overall Dimensions

Height .

1130mm

Ground Contact Length

955mm

Length without Attachment

2020mm

Turning Radius with Standard Bucket

1570mm

Length with Standard Bucket

2642mm

Width

1000mm

Operating Height .

2602mm

Wheel Tread (over tracks)

800mm

Rollback @carry Position

25°

Width with 36" Bucket .

1250mm

Rollback Fully Raised @ Max. Height

102 °

Bucket

Bucket capacity

0.3m3

Bucket width

1250 mm

Performance

Operating Capacity(35%)

238 kg

Operating Capacity (50%)

340 kg

Tipping Capacity

680kg

Weight(no attachment)

1090 kg

Travel Speed

5.6 km/h

Engine

Travel System

Model

Kubota // D1105

Main Drive

Fully hydraulic

Fuel/Cooling .

Diesel/Liquid

Tracks

200mm width

No.Engine cylinder

3

Rollers

3 Each side

Bore and stroke

78mm/78.4 mm

Pressure

25.4Kpa

Displacement

1. 123L

Transmission  :

Direct drive of hydraulic motor to main undercarriage drive sprocket

Power output

18.5kw/3000rpm

Fuel Consumption

6. 1L/h

Controls

Refilling Capacity & lubrication

Vehicle Steering

Direction& Speed controlled by handle

Cooling System

5.2L

Auxiliary Pressure Release

Hand lever moved F/R after engine off

Fuel Tank

35L

Engine

Hand lever throttle  Electric Starting

Engine Oil with Filter

5. 1L

Starting Aid

Glow Plugs – Activated by  key switch

Hydraulic System

40L
