0.9Ton Wheel Loader DH1090 Main Specifications
|
Basic Parameters |
Overall weight(kg) | 2500 |
| L×W×H(mm) | 4200×1450×2280 | |
| Rated bucket capacity(m3) | 0.25 | |
| Rated load(kg) | 800 | |
| Dump height (mm) | 2200 | |
| Lifting height(mm) | 2650 | |
| Dump distance(mm) | 700 | |
| Wheelbase(mm) | 2100 | |
| Thread(mm) | 1405 | |
| Oscillation angle | 8° | |
| Maximum steering angle | 31° | |
| Total time（s） | 11 | |
| Engine | Model | Chang Chai ZN390 |
| Horsepower（HP) | 34 | |
| Type | direct injection, horizontal, water-cooled, four stroke, 3 cylinders | |
| Rated power(KW) | 25 | |
| Rated speed(r/min) | 2200 | |
| Min fuel-consume ratio | ≤1800g/kw.h | |
|
Hydraulic system |
System working pressure (Mpa) | 18 |
| Boom lifting time (s) | 4 | |
| Total time (s) | 7 | |
| Fuel tank capacity (L) | 55 | |
| Hydraulic oil tank capacity（L） | 65 | |
| Function of leveling automatically | Yes | |
|
Transmission system |
Standard | Full Hydraulic |
| Gearbox mode | Power shift normally engaged straight gear | |
| Gear shift | 2forward shift 2 reverse shift | |
| Maximum speed(KM) | 22 | |
|
Brake system |
Service brake | Foot, drum brake |
| Parking brake | Manual disc brake | |
| Tire | Standard tires | 10-16.5 |
| Optional tires | 31X15.5-15 | |
| Front tyre pressure （kPa） | 320 | |
| Rear tyre pressure （kPa） | 320 |
